36mm 24V DC Planetary Gear Motor High Torque 20w For Electric Bicycle

36mm 24V DC Planetary Gear Motor High Torque 20w For Electric Bicycle
36mm 24V DC Planetary Gear Motor High Torque 20w For Electric Bicycle 36mm 24V DC Planetary Gear Motor High Torque 20w For Electric Bicycle 36mm 24V DC Planetary Gear Motor High Torque 20w For Electric Bicycle 36mm 24V DC Planetary Gear Motor High Torque 20w For Electric Bicycle

Large Image :  36mm 24V DC Planetary Gear Motor High Torque 20w For Electric Bicycle

Product Details:
Place of Origin: China
Brand Name: ASLONG
Certification: Rosh,CE
Model Number: PG36-36ZY
Payment & Shipping Terms:
Minimum Order Quantity: 2 Pieces
Price: Negotiation
Packaging Details: on-the-spot foaming package 13*10*8 20*15*10 42*32*16 42*32*32
Delivery Time: 5-8Working days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 10000pcs/week

36mm 24V DC Planetary Gear Motor High Torque 20w For Electric Bicycle

Description
Usage: Home Appliance,Electric Bicycle, Car Speed(rpm): 56-296rpm
Type: 36 Mm Micro Planetary Gear Motor Protect Feature: Totally Enclosed
Torque: 8-35.0kg.cm Voltage(v): 24v
Product Name: Micro DC Planetary Gearbox Motor Diameter: 36mm
High Light:

36mm 20w Planetary Gear Motor

,

20w 24V DC Planetary Gear Motor

,

36mm planetary gearbox motor

36mm 24V DC Planetary Gear Motor High Torque 20w For Electric Bicycle



36mm High Torque 24V DC Micro Planetary Gear Motor 20w Power Planet Gearbox Speed Ruducer Motor​



Specification:

Rated voltage:24VDC,Voltage range:0-24VDC

Metal Planetary Gear

Torque:Max 90kg.cm

Power: Max 25W

Direction: CW, CCW



Datasheet:

Model Number No load Rated Stall Weight
Rated voltaqe Speed Current Speed Current Torque Power Torque Current
V RPM A RPM A KG.CM W KG.CM A g
PG36-36ZY-27K 24 290 0.2 236.0 1.4 8.0 33.0 30.0 6.3 450.0
PG36-36ZY-142K 24 56 0.4 43.0 1.7 35.0 40.0 95.0 6.1 500.0

Reminder :Your project load should not exceed load rated torque of the motor, otherwise the life of the motor will be reduced or burned





Dimensions (unit:mm):



36mm 24V DC Planetary Gear Motor High Torque 20w For Electric Bicycle 036mm 24V DC Planetary Gear Motor High Torque 20w For Electric Bicycle 1
