2386rpm Small Planetary Gear Motor 24v Dc Motor With Gearbox

Certification
China Shenzhen Jinshunlaite Motor Co., Ltd. certification
China Shenzhen Jinshunlaite Motor Co., Ltd. certification
I'm Online Chat Now

2386rpm Small Planetary Gear Motor 24v Dc Motor With Gearbox

2386rpm Small Planetary Gear Motor 24v Dc Motor With Gearbox
2386rpm Small Planetary Gear Motor 24v Dc Motor With Gearbox
2386rpm Small Planetary Gear Motor 24v Dc Motor With Gearbox 2386rpm Small Planetary Gear Motor 24v Dc Motor With Gearbox

Large Image :  2386rpm Small Planetary Gear Motor 24v Dc Motor With Gearbox

Product Details:
Place of Origin: China
Brand Name: ASLONG
Certification: Rosh,CE
Model Number: PG28-395
Payment & Shipping Terms:
Minimum Order Quantity: 2 Pieces
Price: USD30/pcs
Packaging Details: on-the-spot foaming package 13*10*8 20*15*10 42*32*16 42*32*32
Delivery Time: 5-8working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000pcs/Week

2386rpm Small Planetary Gear Motor 24v Dc Motor With Gearbox

Description
Usage: Home Appliance,Car,Boat,Electric Bicycle Speed(rpm): 17~2386rpm
Torque: 0.37-28.4Kg.cm Voltage(v): 24V
Motor Type: Small Planetary Gear Motor Diameter: 28mm
High Light:

24v Small Planetary Gear Motor

,

2386rpm Small Planetary Gear Motor

,

2386rpm 24v dc motors

2386rpm Small Planetary Gear Motor 24v Dc Motor With Gearbox



36D High Torque 90kg.cm 24V DC Micro Planetary Gear Motor 20w Power Planet Gearbox Speed Ruducer Motor



Specification:

Rated voltage:12VDC,Voltage range:0-12VDC

Metal Planetary Gear

Torque:Max 7kg.cm

Power: Max 6W

Direction: CW, CCW



Voltage/rpm/shaft can be customized , welcome to consult.





Model number: PG28-395
Rated DC 24V testing parameter datasheet
Reduction ratio(1:00) 3.353 4.636 11.243 15.544 21.492 37.696 52.12 72.064 99.639 126.396 174.76 241.632 334.09 461.27
No Load speed (rpm) 2386 1726 712 515 372 212 153 111 80 63 46 33 24 17
No Load Current (A) 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1
Rated torque(kg.cm) 0.37 0.43 0.74 1.79 2 2.26 3.39 4.06 4.73 5 15.63 17.84 26.3 28.4
Rated speed (rpm) 1324 1243 562 322 260 174 112 90 71 53 35 27.3 19 15
Rated Current(A) 0.764 0.623 0.462 0.615 0.55 0.407 0.534 0.44 0.359 0.345 0.634 0.515 0.611 0..42
Output(w) 5.13 5.59 4.35 6.03 5.44 4.1 3.94 3.82 3.51 2.78 5.71 5.1 5.18 4.46
Stall Torque (kg.cm) 0.86 1.35 3 4.32 6.5 11 12.2 17 22.8 29.6 37.2 54.2 Forbidden Stall
Stall Current(A) 1.464 1.72 1.54 1.525 1.518 1.61 1.86 1.526 1.5641 1.525 1.488 1.525
Gearbox Length(mm) 23.2 29.8 36.4 43
Weight(g): 140 160 180 200
