Product Details:
Place of Origin: CHINA
Brand Name: ASLONG
Certification: CE,CC
Model Number: JGY-N20
Payment & Shipping Terms:
Minimum Order Quantity: 2 Pieces
Price: Negotiation
Packaging Details: on-the-spot foaming package 13*10*8 20*15*10 42*32*16 42*32*32
Delivery Time: 2-5 work days
Payment Terms: D/P, T/T, Western Union, MoneyGram, L/C
Supply Ability: 5000 Pieces Per Day

ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g

Description
Type: Worm Gearbox Motor Usage: Home Appliance,door Lock,bicycle
Speed(rpm): 13-271rpm Torque: 0.3-3kg.cm
Voltage(v): 12v Weight: 19g

N20 Small DC Gear Motors



ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 0ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 1







Description:



The 3V 6V 12V N20 Dc geared motor, DC Motor (High Torque) is a lightweight, high torque, and low RPM motor. This motor is equipped with a gearbox assembly to increase the torque of the motor. It has a cross-section of 10 × 12 mm, and the D-shaped gearbox output shaft is customization long and 3 mm in diameter.



This motor has low energy consumption and low noise. Replacement of spare parts will make your electrical and testing equipment look new. The bearing quality and the service life of the geared motor are improved, and it is extremely durable.



Because of its small size, the motor fits in complex spaces of small-scale applications. One can connect this Micro Gear Motor to wheels to drive them from one place to another while carrying high loads.



The motor is used in DIY RC Hobby, vehicles, drones, airplanes, etc., the miniature gearbox motor, it is an excellent substitute for the rusty or damaged DC geared motor on the machine.



Now ,you can get our this 12mm dc gear motor with magnetic encoder(JGA12-N20B),and other related 12mm gearbox motors as following:



ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 2 ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 3 ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 4 ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 5
JGA12-N20B JGA12-N10 JGA12-N30 JGA1024-N20
ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 6 ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 7 ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 8 ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 9
JGY-N20 JGY-N20S JGA12-N20 sets GM12-15by






【Product information】

[Model:JGY-N20】

[Power:1.02W】

[Rated voltage: 12V]

[No-load current:30MA]

[No load speed:16-381RPM]

[Motor size:10 * 18mm]

[Output shaft diameter:3mm】

[Adjustable speed Reversible]
[Customizable shaft length, speed, and voltage]





ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 10



ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 11ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 12ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 13ASLONG JGY-N20 12V 16-381RPM Turbine Worm Reduction Motor with Self Locking Small Motor high torque metal gearbox worm g 14

Datasheet:



Model No load On Load Stall Power
Workable Voltage Speed Current Speed Current Torque Torque Current
V rpm A rpm ma gf.cm gf.cm ma W
JGY-N20 12 271 30 216 85 71 235.2 700 1.02
12 136 30 119 85 142 472 700 1.02
12 68 30 59 85 283 844 700 1.02
12 53 30 46 85 362 1208 700 1.02
12 27 30 23 85 579 1929.6 700 1.02
12 13 30 14 85 975 3251.2 700 1.02
