Product Details:
|
| Product Type: | Mini Low-speed Small Motor Circular Shaft | Voltage: | 12V |
|---|---|---|---|
| No-load Speed: | 20-2272RPM | Output Shaft Diameter: | 4MM (D-axis) |
| Motor Size: | 25mm |
| JGA25-370 Micro Dc Gear Motor Description: |
Now ,you can get our this 25mm dc gear motor with magnetic encoder(JGA25-370B),and other related 25mm gearbox motors as following:
|
|
|
|
| JGA25-370B | JGA25-310 | JGA25-385 | JGA25-340 |
|
|
|
|
| JGA25-2418 | JGA25-2430 | JGA25-370TC |
JGA25-370DG |
【Manufacturer's direct store】
We are a professional manufacturer of various DC reduction motors for over 14 years. We not only provide stable and excellent quality, but also provide excellent services. If you need customized parameters and mass production, we can provide you. Please feel free to contact us for more details.
【Quality of motor】
We have specialized equipment for testing and developing motors. We use all metal gear motors with long lifespan and noise. We will never cut corners to save costs. We will conduct strict testing on the motor before shipment to ensure that it meets the requirements.
【Give service to】
We will provide you with excellent service both before and after sales. You can always contact me for more product details.
【Product information】
| Made of high-quality materials, it is not easy to rust or corrode. | |
| Small motor, high torque | |
| 25mm diameter metal gear reducer |
【Model:JGA25-385】
【Working volt range: 12V】
【No-loading Rotation speed:20-2272RPM】
| Model: JGA25-385 | No load | On Load | Stall | Ratio | Size(L) | Weight | ||||||
| Rated Voltage | Speed | Current | Speed | Current | Torque | Power | Torque | Current | ||||
| Workable Voltage | V | rpm | ma | rpm | ma | Kg.cm | W | Kg.cm | A | 1:00 | mm | g |
| 12-24V | 24 | 1818 | 70 | 1454 | 450 | 0.32 | 6 | 1.2 | 2 | 4.4 | 15 | 100 |
| 12-24V | 24 | 833 | 70 | 666 | 450 | 0.72 | 6 | 2.8 | 2 | 9.28 | 17 | 105 |
| 12-24V | 24 | 380 | 70 | 304 | 450 | 1.7 | 6 | 6 | 2 | 21.3 | 19 | 110 |
| 12-24V | 24 | 228 | 70 | 182 | 450 | 2.7 | 6 | 10 | 2 | 34 | 21 | 115 |
| 12-24V | 24 | 177 | 70 | 141 | 400 | 3 | 6 | 12 | 2 | 45 | 21 | 115 |
| 12-24V | 24 | 102 | 70 | 81 | 400 | 6 | 6 | 24 | 2 | 78 | 23 | 120 |
| 12-24V | 24 | 77 | 70 | 61 | 400 | 8 | 6 | 32 | 2 | 103 | 23 | 120 |
| 12-24V | 24 | 46 | 70 | 36 | 400 | 13 | 6 | 52 | 2 | 171 | 25 | 125 |
| 12-24V | 24 | 35 | 70 | 28 | 400 | 18 | 6 | 70 | 2 | 226 | 25 | 125 |
| 12-24V | 24 | 21 | 70 | 16 | 400 | 30 | 6 | 70 | 2 | 378 | 27 | 130 |
| 12-24V | 24 | 16 | 70 | 12 | 400 | 30 | 6 | 70 | 2 | 500 | 27 | 130 |
【The characteristics of this product are central shaft, high torque, and all metal】
【Mini low-speed small motor circular shaft】
【Center output shaft】
【Wiring method 】
【Forward rotation: The one with a red dot or a "+" sign is connected to the positive pole of the power supply. The other side is connected to the negative pole of the power supply.】
【Reverse: The positive and negative power supplies are connected in reverse.】
[FAQ]
1)What's the price?
We're a professional manufacturer So the exact price is based on clients' specifications,
such as the speed,voltage etc.
2)What's the MOQ?
We try to meet every client's requests and don't want to disappoint our clients.
So the MOQ is flexible if the product is not complicated to produce and we are not in a busy season.
Kindly chat with our saler to confirm it.
3)What's the delivery time?
At the first we have an schedule,the earlier you place order,the fater we finish the production.
In the slack season,we can make sure the delivery time is by one month.
In the busy season,we need more than one month if your quantity is large.
The most important,we can provide free overtime prodution if your order is really urgent.
4)Can you send some samples before the order?
Yes of course,we must send the sample to confirm the quality with you first.
UPS,TNT,FEDEX or DHL are all available.
5)Can you make our logo on the products?
Certainly,logo is easy as most of our products are customizable.
So logo in usually logo is necessary.It can be labeled on the motors.
6)What's the payment term?
For small amount,we accept 100% payment via paypal.
For large amount,we accept 30% telegraphic transfer(TT) as the deposit.
And the rest must be paid before shipping.
7)How to deliver the goods?
we will deliver via Express such as UPS,FEDEX,DHL,TNT etc.
It is fast and safety.If goods quantity is large,the shipping cost will be cost-effective.
8)Can you make our logo on the products?
Certainly,logo is easy as most of our products are customizable.
So logo in usually logo is necessary.It can be printed,emboridered,embossed/jacquard.
9)What's the payment term?
For small amount,we accept 100% payment via Western Union.
For large amount,we accept 30% telegraphic transfer(TT) as the deposit.
And the rest must be paid before shipping.
10)How to deliver the goods?
If goods quantity is small,we will deliver via Express such as UPS,FEDEX,DHL,TNT etc.
It is fast and clients don't need to pay the custom charge.
If goods quantity is large,we will ship by sea.It will be very economical.
11)Does your company supply to any famous hotels?
As a leading manufactuer of hotel products,we have many famous hotel and resort clients.
Such as InterContinental Hotels Group,Marriott Hotel,The Ritz Carlton Hotel and son on.
If you need some samples of them,we can send out.
12)Any other questions kindly chat with our sales,they will do the best to serve you.
