24byj48 12v Dc 4 Phase 5 Wire Stepper Motor Rosh Approved

24byj48 12v Dc 4 Phase 5 Wire Stepper Motor Rosh Approved
24byj48 12v Dc 4 Phase 5 Wire Stepper Motor Rosh Approved 24byj48 12v Dc 4 Phase 5 Wire Stepper Motor Rosh Approved 24byj48 12v Dc 4 Phase 5 Wire Stepper Motor Rosh Approved 24byj48 12v Dc 4 Phase 5 Wire Stepper Motor Rosh Approved 24byj48 12v Dc 4 Phase 5 Wire Stepper Motor Rosh Approved

Large Image :  24byj48 12v Dc 4 Phase 5 Wire Stepper Motor Rosh Approved

Product Details:
Place of Origin: China
Brand Name: ASLONG
Certification: Rosh ,CE
Model Number: 24BYJ48
Payment & Shipping Terms:
Minimum Order Quantity: 10 Pieces
Price: Negotiation
Packaging Details: on-the-spot foaming package 13*10*8(cm) 20*15*10(cm) 42*32*16(cm) 42*32*32(cm)
Delivery Time: 5-8working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/Week

24byj48 12v Dc 4 Phase 5 Wire Stepper Motor Rosh Approved

Description
Phase: 4 Voltage: 12v
Size: 24*19mm Reduction Ratio: 1/36
Name: 4 Phase 5 Wire Stepper Motor
High Light:

24byj48 5 Wire Stepper Motor

,

Rosh 5 Wire Stepper Motor

,

Rosh 24byj48 stepper motor

24byj48 12v Dc 4 Phase 5 Wire Stepper Motor Rosh Approved​



24BYJ48 DC 12V CNC Motor Reducing Stepping Stepper Motor 24BYJ48 Step Motor 4 Phase 5 Wire Speed Reducing Components



Features:
Easy to install and use.
Lightweight and durable.

Size Φ24*19mm
Voltage 12V DC
Phase 4
Reduction Ratio 1 /36
Basic step Angle 5.625°/36
Excitation Mode 1-2 Phase Excitation
Output Torque ≥400gf.cm(5V DC,400PPS)
Max response cycle number ≥1000PPS
Maximum self-starting cycle number ≥500PPS
DC resistance 25Ω±10%(25℃)
Insulation Resistance ≥50MΩ(500V)
Terminal Angle 5P*1.5
Verticality of output shaft 90±1°
Shaft Clearance 0.05~0.3MM

Note:
1.Please allow 0.1-0.3cm differences due to manual measurement, thanks.
2.Please understand because of the light irradiation or computer display difference, so I can't guarantee photos and real color is 100% the same.





FAQ
1. who are we?
We are based in Guangdong, China, start from 2005,sell to North America(30.00%),Domestic Market(15.00%),Western Europe(10.00%),Eastern Europe(10.00%),Northern Europe(6.00%),Southern Europe(5.00%),Southeast Asia(5.00%),South America(5.00%),Oceania(5.00%),South Asia(4.00%),Africa(3.00%),Eastern Asia(2.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Gear Motor,DC Motor,Brushless Motor,Planetary Gear Motor,Worm Gear Motor

4. why should you buy from us not from other suppliers?
Specialized in Micro DC motor, Dc Gearbox motor.We have been in this industry for over 10 years,we have many experinec to provide motors according to customer's requirements.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,Express Delivery;
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card,PayPal;
Language Spoken:English,Chinese
