JGA25-385 Carbon Brush Micro DC Gear Motors 25mm 24V For Robotics

JGA25-385 Carbon Brush Micro DC Gear Motors 25mm 24V For Robotics
JGA25-385 Carbon Brush Micro DC Gear Motors 25mm 24V For Robotics JGA25-385 Carbon Brush Micro DC Gear Motors 25mm 24V For Robotics JGA25-385 Carbon Brush Micro DC Gear Motors 25mm 24V For Robotics JGA25-385 Carbon Brush Micro DC Gear Motors 25mm 24V For Robotics

Large Image :  JGA25-385 Carbon Brush Micro DC Gear Motors 25mm 24V For Robotics

Product Details:
Place of Origin: CHINA
Brand Name: ASLONG
Certification: CE,CC
Model Number: JGA25-385
Payment & Shipping Terms:
Minimum Order Quantity: 2 Pieces
Price: Negotiation
Packaging Details: on-the-spot foaming package 13*10*8 20*15*10 42*32*16 42*32*32
Delivery Time: 2-5 work days
Payment Terms: D/P, T/T, Western Union, MoneyGram, L/C
Supply Ability: 5000 Pieces Per Day

JGA25-385 Carbon Brush Micro DC Gear Motors 25mm 24V For Robotics

Description
Construction: Permanent Magnet Torque: 0.32-30kg.cm
Voltage(v): 12-24V Weight: 130g
Certification: ROHS,CE Motor Type: Dc Brush Gear Motor
High Light:

JGA25-385 25mm Micro DC Gear Motors

,

JGA25-385 24V Micro DC Gear Motors

,

JGA25-385 24V metal gearmotor

JGA25-385 Carbon Brush Micro DC Gear Motors 25mm 24V For Robotics



Mirco Dc Gear Motors JGA25-385 High Power Carbon Brush 25mm Gearbox Dc Gear Motor For Robotics





Model
JGA25-385 metal gearmotor
Name
DC Geared Motor
Voltage
24V
Power
3.8W
No-load Speed
15-1727RPM
Electric Current
160mA
Product Shaft Diameter
4MM (Can be customise)
Product Shaft Length
10MM
Maximum Torque
20KG.CM
Weight
133g(APPROX)
Whether to adjust the speed
Yes
Whether forward or reverse
Yes

Mirco Dc gear Motors JGA25-385 High power carbon brush 25mm gearbox dc gear motor for robotics

Voltage/rpm/shaft can be customized , welcome to consult.





Datasheet:



Model: JGA25-385 No load On Load Stall Ratio Size(L) Weight
Rated Voltage Speed Current Speed Current Torque Power Torque Current
Workable Voltage V rpm ma rpm ma Kg.cm W Kg.cm A 1:00 mm g
12-24V 24 1727 70 1200 450 0.32 6 1.2 2 4.4 15 100
12-24V 24 818 70 572 450 0.72 6 2.8 2 9.28 17 105
12-24V 24 356 70 249 450 1.7 6 6 2 21.3 19 110
12-24V 24 223 70 156 450 2.7 6 10 2 34 21 115
12-24V 24 168 70 117 400 3 6 12 2 45 21 115
12-24V 24 97 70 67 400 6 6 24 2 78 23 120
12-24V 24 73 70 51 400 8 6 32 2 103 23 120
12-24V 24 44 70 30 400 13 6 52 2 171 25 125
12-24V 24 33 70 23 400 18 6 70 2 226 25 125
12-24V 24 20 70 14 400 30 6 70 2 378 27 130
12-24V 24 15 70 10 400 30 6 70 2 500 27 130





FAQ



1. who are we?
We are based in Guangdong, China, start from 2005,sell to North America(30.00%),Domestic Market(15.00%),Western Europe(10.00%),Eastern Europe(10.00%),Northern Europe(6.00%),Southern Europe(5.00%),Southeast Asia(5.00%),South America(5.00%),Oceania(5.00%),South Asia(4.00%),Africa(3.00%),Eastern Asia(2.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Gear Motor,DC Motor,Brushless Motor,Planetary Gear Motor,Worm Gear Motor

4. why should you buy from us not from other suppliers?
Specialized in Micro DC motor, Dc Gearbox motor.We have been in this industry for over 10 years,we have many experinec to provide motors according to customer's requirements.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,Express Delivery;
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card,PayPal;
Language Spoken:English,Chinese
